Max Scan Volume (mm)
300 L x 100 Ø with SG156 Scanhead
ShapeGrabber Ai320 is an automatic, compact 3D scanner designed to serve a wide variety of parts in minutes with a high density of data points. Ai320 offers:
Metrology Grade 3D Scanning – Ideal for measuring complex shapes in a variety of colors and finishes due to a 360° rotary table and vertical motion. Excels in rapid prototyping, manufacturing, quality control, and reverse engineering applications.
Ease of Use – Scans can be initiated with one click, delivering consistent measurement results by any operator. Scanning parameters are easily selected and saved – there is no need to write special code.
Accurate, High Density Point Data– The SG108 scanhead moves vertically on a high precision motion assembly and can obtain more than 1,500,000 points per second.
Technical Data
| Standard | |
|---|---|
| Max Scan Volume (mm) | 300 L x 100 Ø with SG108 Scanhead |
| Data Rate (Pts/s) | 155,000 – 1,500,000+ |
